Pfadfinder EVO
Discover new paths off the road with the new PFADFINDER EVO
To stay in full control, you need a wheel that not only delivers precision and performance but also executes every maneuver safely and comfortably. With a tire width of up to 40 mm, tubeless technology, and a new carbon layup, PFADFINDER EVO provides everything you need for gravel.
Features
- Lightweight (Set 1430 g/ FW 670 g/ RW 760 g)
- Familiar simple handling through tubeless/clincher tires
- Disc brake system
- 20 full carbon spokes in the front and rear wheel make for more stiffness and consequently for a direct power transmission without energy loss
- Rim width of 24 mm and tire width of up to 40 mm
- Optimized layup makes for significantly increased robustness
- Outstanding stiffness to weight ratio
- Unique rolling characteristics
- Perfectly suited for all-round, training, competition, gravel, and endurance
The Schwarz ED also offers:
Understatement with simple clarity: Spokes, rim, and logos in black
Longer durability and reduced rolling resistance thanks to CeramicSpeed ball bearings
Specifications
PFADFINDER EVO LAUFRADSATZ | 20/20 | SCHWARZ ED | SRAM 12
Braking System | Disc |
Rim type | Tubeless |
Wheel Type | Set |
No. of spokes | 20/20 |
Label | - |
Switching system | SRAM 12 |
Axle system | 12/100 / 12/142 |
Weight FW | 670 gr |
Weight BW | 760 gr |
Weight set | 1430 gr |
Rim depth | 36 mm |
Outer rim width | 24 mm |
Internal rim width | 18,2 mm |
Tyre width | 23-40 mm |
Max. system weight | 120 kg |
