Frame |
Trek 800 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube shape, adjustable top tube IsoSpeed, invisible cable routing, 3S aero chain keeper, T47 BB, DuoTrap S compatible, flat mount disc, 142x12mm thru-axle |
Fork |
Trek Madone KVF full carbon, tapered carbon steerer, invisible cable routing, flat mount disc, carbon dropouts, 12x100mm thru-axle |
Headset |
Madone integrated, stainless cartridge bearings, sealed, 1-3/8˝ top, 1.5˝ bottom |
Bottom Bracket |
Praxis Works, T47 threaded, internal bearing |
Stem |
Trek Madone aero, invisible cable routing, 7 degree |
Handlebar |
Trek Madone adjustable aero VR-CF, OCLV Carbon, invisible cable routing, 93mm reach, 123mm drop |
Bar Tape |
Bontrager Supertack Perf tape |
Front Brake |
Shimano Dura-Ace hydraulic disc, flat mount |
Rear Brake |
Shimano Dura-Ace hydraulic disc, flat mount |
Brake Levers |
Shimano Dura-Ace Di2 R9170 |
Front Derailleur |
Shimano Dura-Ace Di2 R9150, braze-on |
Rear Derailleur |
Shimano Dura-Ace Di2 R9150, short cage, 30T maximum cog |
Shift Levers |
Shimano Dura-Ace Di2 R9170, 11-speed |
Chain |
Shimano Dura-Ace 9000, 11-speed |
Cassette |
Shimano Dura-Ace R9100, 11-30, 11-speed |
Crankset |
Shimano Dura-Ace R9100 Power Meter, 52/36 |
Front Wheel |
Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth, 100x12mm |
Rear Wheel |
Bontrager Aeolus XXX 6, OCLV Carbon, Tubeless Ready, 21mm rim width, 60mm rim depth, SRAM XD-R driver, 142x12mm |
Front Tyre |
Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c, clincher |
Rear Tyre |
Bontrager R4 320 Handmade Clincher, Hard-Case Lite, 320 tpi, 700x25c, clincher |
Saddle |
Bontrager Aeolus Pro, carbon rails, 145mm width |
Seatpost |
Trek Madone aero carbon internal seatmast cap, integrated light mount, 25mm offset |
Pedals |
Available to purchase separately |
